SC to ST Duplex Hybrid Adapter With Rectangular Flange Plastic

Aminite supply the SC to ST Duplex Hybrid Adapter With Rectangular Flange Plastic, These hybrid adapters are single mode and multimode types,has a high-precision sleeve and high performance,Can be Compact design. They are widely used in the fiber optic links.

Tags: , , , , ,
General Details
We offers the SC to ST Duplex Hybrid Adapter With Rectangular Flange Plastic, There are different colors of the choice of this fiber optic adapter

SC to ST Duplex Hybrid Adapter With Rectangular Flange Plastic

The SC to ST Duplex Hybrid Adapter With Rectangular Flange Plastic offer a solution for hybrid applications where the two different kinds of fiber optic connectors or cable assemblies need to be linked with each other. Most of the hybrid fiber adapters use high precision ceramic sleeves which enable reliable ferrule mating and ensure low insertion loss and return loss during the linking.

  1. Application
  • Network environments integrating different configurations
  • Telecommunication networks
  1. Features
  • High-precision sleeve
  • Compact design
  • High performance
  • Ultra low insertion loss
  • With or without flange options for installation flexibility
  • RoHS compliant
  1. Compliance
  • IEC60B74-14;F04 (JIS C5973);FOCIS-3;TIA/EIA-604-3A;
  • Telcordia GR-326-4 CORE Compliant
  • UL94 V-0 rated plastic housing or metal housings available
  1. Specification
SPECIFICATION Zirconia SLEEVE Phosohor Bronze Sleeve
Insertion Loss Typical≤0.05dB,Max≤0.2dB Typical≤0.1dB,Max≤0.3dB
Durability <0.1dB Typical change,500 matings
Note:Zirconia tested with SMF Fiber,Phosphor Bronze sleeve tested with MMF
  1. Sleeves
  • Zirconia Sleeves Adapters

zirconia-sleeves-adapters

ZIRCONIA-SLEEVES-ADAPTOR-detail

  • Phosphor Bronze Adapter Sleeve

Phosphor-bronze-adapter-sleeve

PHOSPHOR-BRONZE-ADAPTOR-sleeve-detail

  1. Images
    SC to ST Duplex Hybrid Adapter With Rectangular Flange Plastic

    SC to ST Duplex Hybrid Adapter With Rectangular Flange Plastic
